Potential spatial distribution pattern and landscape connectivity of Pelophylax plancyi in Shanghai, China

doi:10.17520/biods.2022692

Abstract

Abstract:

Aims: Habitat fragmentation and loss caused by urbanization are important factors that threaten the survival of wildlife globally. Urbanization has caused amphibians to become one of the most severely threatened groups of terrestrial vertebrates. Studying the spatial distribution pattern and exploring how landscape connectivity affects the gene flow among fragmented populations of amphibians in urban areas would provide a deeper understanding of the impacts of urbanization on wildlife and offer theoretical guidance for local biodiversity conservation.
Methods: In this study, we selected the eastern golden frog (Pelophylax plancyi) as the primary research subject and obtained landscape and environmental data about land cover, normalized difference vegetation index (NDVI) and land surface temperature in the Shanghai region using Landsat-8 satellite images (http://www.gscloud.cn). Combined with the data from field population survey, we employed the maximum entropy (MaxEnt) model to predict the spatial distribution pattern of P. plancyi in the region. We evaluated the potential corridors and calculated the resistance distances between local populations using circuit theory (Circuitscape), and explored the effect of geographical and resistance distance on genetic differentiation among local populations using the Mantel test of each local populations based on the genetic distance (F_ST) matrices calculated from simple sequence repeat (SSR) and single nucleotide polymorphism (SNP).
Results: The habitat suitability of P. plancyi significantly decreased along the rural-to-urban gradient. NDVI was the main factor affecting the MaxEnt modelling and indicated that the P. plancyi prefer to inhabit areas with higher vegetation coverage. There was no significant correlation between genetic distance and geographical distance, while genetic distance increased significantly with the resistance distance.
Conclusions: The protection and maintenance of continuous suitable habitats in suburbs and isolated habitat patches in urban areas that still exist is the primary measure of conservation for native amphibians such as P. plancyi. Furthermore, optimizing urban landscape structure, strengthening the construction of corridors suitable for various groups of wildlife, and promoting the gene exchange among local populations are effective methods to achieve the self-sustainment of populations and long-term conservation of biodiversity in urbanized areas.

Key words: urbanization, MaxEnt, circuit theory, isolation by resistance, Pelophylax plancyi, Shanghai

Tingwei Dong, Meiling Huang, Xu Wei, Shuo Ma, Qu Yue, Wenli Liu, Jiaxin Zheng, Gang Wang, Rui Ma, Youzhong Ding, Shunqi Bo, Zhenghuan Wang. Potential spatial distribution pattern and landscape connectivity of Pelophylax plancyi in Shanghai, China[J]. Biodiv Sci, 2023, 31(8): 22692.

Add to citation manager EndNote|Ris|BibTeX

URL: https://www.biodiversity-science.net/EN/10.17520/biods.2022692

https://www.biodiversity-science.net/EN/Y2023/V31/I8/22692

Figures/Tables 7

References 43

[1]	Botzat A, Fischer LK, Kowarik I (2016) Unexploited opportunities in understanding liveable and biodiverse cities. A review on urban biodiversity perception and valuation. Global Environmental Change, 39, 220-233. DOI URL
[2]	Danecek P, Auton A, Abecasis G, Albers CA, Banks E, DePristo MA, Handsaker RE, Lunter G, Marth GT, Sherry ST, McVean G, Durbin R, 1000 Genomes Project Analysis Group (2011) The variant call format and VCFtools. Bioinformatics, 27, 2156-2158. DOI URL
[3]	Deng SB, Du HJ, Xu EH, Chen JQ (2014) ENVI Remote Sensing Image Processing Method, 2nd edn. Higher Education Press, Beijing. (in Chinese)
	[ 邓书斌, 杜会建, 徐恩惠, 陈秋锦 (2014) ENVI遥感图像处理方法(第二版). 高等教育出版社, 北京.]
[4]	Diao YX, Zhao QQ, Weng Y, Huang ZX, Wu YQ, Gu BJ, Zhao Q, Wang F (2022) Predicting current and future species distribution of the raccoon dog (Nyctereutes procyonoides) in Shanghai, China. Landscape and Urban Planning, 228, 104581. DOI URL
[5]	Dray S, Dufour AB (2007) The ade 4 package: Implementing the duality diagram for ecologists. Journal of Statistical Software, 22(4), 1-20.
[6]	Excoffier L, Laval G, Schneider S (2007) Arlequin (version 3.0): An integrated software package for population genetics data analysis. Evolutionary Bioinformatics Online, 1, 47-50.
[7]	Gippet JMW, Mondy N, Diallo-Dudek J, Bellec A, Dumet A, Mistler L, Kaufmann B (2017) I’m not like everybody else: Urbanization factors shaping spatial distribution of native and invasive ants are species-specific. Urban Ecosystems, 20, 157-169. DOI URL
[8]	Grimm NB, Faeth SH, Golubiewski NE, Redman CL, Wu JG, Bai XM, Briggs JM (2008) Global change and the ecology of cities. Science, 319, 756-760. DOI PMID
[9]	Guzy JC, McCoy ED, Deyle AC, Gonzalez SM, Halstead N, Mushinsky HR (2012) Urbanization interferes with the use of amphibians as indicators of ecological integrity of wetlands. Journal of Applied Ecology, 49, 941-952. DOI PMID
[10]	Hamer AJ, McDonnell MJ (2008) Amphibian ecology and conservation in the urbanising world: A review. Biological Conservation, 141, 2432-2449. DOI URL
[11]	Hu HY (1987) Demography in China (Shanghai Part). China Financial & Economic Publishing House, Beijing. (in Chinese)
	[ 胡焕庸 (1987) 中国人口(上海分册). 中国财政经济出版社, 北京.]
[12]	Huang ZY, Tang ZY, Zong Y (1980) Amphibian and reptile species in Shanghai. Natural Science, (3), 17-20. (in Chinese)
	[ 黄正一, 唐子英, 宗愉 (1980) 上海地区的两栖爬行动物. 博物, (3), 17-20.]
[13]	IUCN International Union for Conservation of Nature (2021) The IUCN Red List of Threatened Species, Version, Version 2021-3. https://www.iucnredlist.org/. (accessed on 2022-07-12)
[14]	Johnson MTJ, Munshi-South J (2017) Evolution of life in urban environments. Science, 358, eaam8327.
[15]	Kuang WH, Chi WF, Lu DS, Dou YY (2014) A comparative analysis of megacity expansions in China and the U.S.: Patterns, rates and driving forces. Landscape and Urban Planning, 132, 121-135. DOI URL
[16]	Li B, Zhang W, Shu XX, Pei EL, Yuan X, Wang TH, Wang ZH (2018) Influence of breeding habitat characteristics and landscape heterogeneity on anuran species richness and abundance in urban parks of Shanghai, China. Urban Forestry & Urban Greening, 32, 56-63.
[17]	Lin P, Yang L, Zhao SQ (2020) Urbanization effects on Chinese mammal and amphibian richness: A multi-scale study using the urban-rural gradient approach. Environmental Research Communications, 2, 125002. DOI
[18]	Magle SB, Hunt VM, Vernon M, Crooks KR (2012) Urban wildlife research: Past, present, and future. Biological Conservation, 155, 23-32. DOI URL
[19]	Mantel N (1967) The detection of disease clustering and a generalized regression approach. Cancer Research, 27, 209-220. PMID
[20]	McRae BH (2006) Isolation by resistance. Evolution, 60, 1551-1561. PMID
[21]	McRae BH, Beier P (2007) Circuit theory predicts gene flow in plant and animal populations. Proceedings of the National Academy of Sciences, USA, 104, 19885-19890.
[22]	Munshi-South J, Zolnik CP, Harris SE (2016) Population genomics of the Anthropocene: Urbanization is negatively associated with genome-wide variation in white-footed mouse populations. Evolutionary Applications, 9, 546-564. DOI PMID
[23]	Phillips SJ, Anderson RP, Schapire RE (2006) Maximum entropy modeling of species geographic distributions. Ecological Modelling, 190, 231-259. DOI URL
[24]	Rousset F (1997) Genetic differentiation and estimation of gene flow from F-statistics under isolation by distance. Genetics, 145, 1219-1228. DOI PMID
[25]	Semlitsch RD (2000) Principles for management of aquatic- breeding amphibians. The Journal of Wildlife Management, 64, 615-631.
[26]	Semlitsch RD (2008) Differentiating migration and dispersal processes for pond-breeding amphibians. The Journal of Wildlife Management, 72, 260-267.
[27]	Seto KC, Güneralp B, Hutyra LR (2012) Global forecasts of urban expansion to 2030 and direct impacts on biodiversity and carbon pools. Proceedings of the National Academy of Sciences, USA, 109, 16083-16088.
[28]	Shanghai Bureau of Statistics (2022) Shanghai Statistical Yearbook 2022. China Statistics Press, Beijing. (in Chinese)
	[ 上海市统计局 (2022) 2022年上海统计年鉴. 中国统计出版社, 北京.]
[29]	Smith MA, Green DM (2005) Dispersal and the metapopulation paradigm in amphibian ecology and conservation: Are all amphibian populations metapopulations? Ecography, 28, 110-128. DOI URL
[30]	Swets JA (1988) Measuring the accuracy of diagnostic systems. Science, 240, 1285-1293. DOI PMID
[31]	Tewksbury JJ, Levey DJ, Haddad NM, Sargent S, Orrock JL, Weldon A, Danielson BJ, Brinkerhoff J, Damschen EI, Townsend P (2002) Corridors affect plants, animals, and their interactions in fragmented landscapes. Proceedings of the National Academy of Sciences, USA, 99, 12923-12926.
[32]	Tsuji M, Ushimaru A, Osawa T, Mitsuhashi H (2011) Paddy-associated frog declines via urbanization: A test of the dispersal-dependent-decline hypothesis. Landscape and Urban Planning, 103, 318-325. DOI URL
[33]	United Nations (2019) World Urbanization Prospects: The 2018 Revision. https://esa.un.org/unpd/wup/publications. (accessed on 2022-11-28)
[34]	Wang IJ (2013) Examining the full effects of landscape heterogeneity on spatial genetic variation: A multiple matrix regression approach for quantifying geographic and ecological isolation. Evolution, 67, 3403-3411. DOI PMID
[35]	Wang IJ, Glor RE, Losos JB (2013) Quantifying the roles of ecology and geography in spatial genetic divergence. Ecology Letters, 16, 175-182. DOI PMID
[36]	Wang M, Li JX, Kuang SJ, He YJ, Chen GJ, Huang Y, Song CH, Anderson P, Łowicki D (2020) Plant diversity along the urban-rural gradient and its relationship with urbanization degree in Shanghai, China. Forests, 11, 171. DOI URL
[37]	Wang YH, Yang KC, Bridgman CL, Lin LK (2008) Habitat suitability modelling to correlate gene flow with landscape connectivity. Landscape Ecology, 23, 989-1000.
[38]	Ward DF (2007) Modelling the potential geographic distribution of invasive ant species in New Zealand. Biological Invasions, 9, 723-735. DOI URL
[39]	Wei X, Huang ML, Yue Q, Ma S, Li B, Mu ZQ, Peng C, Gao WX, Liu WL, Zheng JX, Weng XD, Sun XH, Zuo QQ, Bo SQ, Yuan X, Zhang W, Yang G, Ding YZ, Wang XM, Wang TH, Hua PY, Wang ZH (2020) Long-term urbanization impacts the eastern golden frog (Pelophylax plancyi) in Shanghai City: Demographic history, genetic structure, and implications for amphibian conservation in intensively urbanizing environments. Evolutionary Applications, 14, 117-135. DOI URL
[40]	Wright S (1943) Isolation by distance. Genetics, 28, 114-138. DOI PMID
[41]	Yang L, Zhao SQ, Liu SG (2022) A global analysis of urbanization effects on amphibian richness: Patterns and drivers. Global Environmental Change, 73, 102476. DOI URL
[42]	Zhang W, Li B, Shu XX, Pei EL, Yuan X, Sun YJ, Wang TH, Wang ZH (2016) Responses of anuran communities to rapid urban growth in Shanghai, China. Urban Forestry & Urban Greening, 20, 365-374.
[43]	Zhao SQ, Da LJ, Tang ZY, Fang HJ, Song K, Fang JY (2006) Ecological consequences of rapid urban expansion: Shanghai, China. Frontiers in Ecology and the Environment, 4, 341-346. DOI URL

采样点 Sampling site	分布区域 Region	城市化水平 Urbanization degree	生境适宜均值 Mean of habitat suitability	GPS坐标数 Number of GPS positions	样本量(只) Sampling size
采样点 Sampling site	分布区域 Region	城市化水平 Urbanization degree	生境适宜均值 Mean of habitat suitability	GPS坐标数 Number of GPS positions	微卫星位点分析样本Samples for SSR analysis	单核苷酸多肽位点分析样本 Samples for SNP analysis
世纪公园 Century Park (CP)	中心城区 Central urban area	0.734	0.236	15	32	10
上海植物园 Shanghai Botanical Garden (BG)	中心城区 Central urban area	0.773	0.147	10	28	10
共青森林公园 Gongqing Forest Park (GQ)	中心城区 Central urban area	0.705	0.135	7	16	10
辰山植物园 Chenshan Botanical Garden (CS)	近郊 Suburb	0.393	0.472	-	36	10
松南郊野公园 Songnan Country Park (SN)	近郊 Suburb	0.371	0.417	34	35	10
浦江郊野公园 Pujiang Country Park (PJ)	近郊 Suburb	0.469	0.526	12	15	10
奉贤向阳村 Fengxian Xiangyang Village (XY)	近郊 Suburb	0.412	0.372	-	25	10
浦东五灶港 Pudong Wuzao Port (WG)	近郊 Suburb	0.489	0.410	-	34	10
嘉北郊野公园 Jiabei Country Park (JB)	远郊 Outer suburb	0.530	0.455	14	17	10
青西郊野公园 Qingxi Country Park (QX)	远郊 Outer suburb	0.217	0.469	31	33	10
廊下郊野公园 Langxia Country Park (LX)	远郊 Outer suburb	0.313	0.463	25	39	10
海湾郊野公园 Bay Country Park (BF)	远郊 Outer suburb	0.262	0.519	3	11	10
南汇临港新城 Nanhui Lingang New City (LG)	远郊 Outer suburb	0.530	0.353	-	28	10
长兴岛潘石镇 Changxing Island Panshi Town (PS)	远郊 Outer suburb	0.085	0.280	14	30	10
崇明岛陈家镇 Chongming Island Chenjia Town (CJ)	远郊 Outer suburb	0.570	0.281	-	28	10
总计 Total				165	407	150

采样点 Sampling site	分布区域 Region	城市化水平 Urbanization degree	生境适宜均值 Mean of habitat suitability	GPS坐标数 Number of GPS positions	样本量(只) Sampling size
采样点 Sampling site	分布区域 Region	城市化水平 Urbanization degree	生境适宜均值 Mean of habitat suitability	GPS坐标数 Number of GPS positions	微卫星位点分析样本Samples for SSR analysis	单核苷酸多肽位点分析样本 Samples for SNP analysis
世纪公园 Century Park (CP)	中心城区 Central urban area	0.734	0.236	15	32	10
上海植物园 Shanghai Botanical Garden (BG)	中心城区 Central urban area	0.773	0.147	10	28	10
共青森林公园 Gongqing Forest Park (GQ)	中心城区 Central urban area	0.705	0.135	7	16	10
辰山植物园 Chenshan Botanical Garden (CS)	近郊 Suburb	0.393	0.472	-	36	10
松南郊野公园 Songnan Country Park (SN)	近郊 Suburb	0.371	0.417	34	35	10
浦江郊野公园 Pujiang Country Park (PJ)	近郊 Suburb	0.469	0.526	12	15	10
奉贤向阳村 Fengxian Xiangyang Village (XY)	近郊 Suburb	0.412	0.372	-	25	10
浦东五灶港 Pudong Wuzao Port (WG)	近郊 Suburb	0.489	0.410	-	34	10
嘉北郊野公园 Jiabei Country Park (JB)	远郊 Outer suburb	0.530	0.455	14	17	10
青西郊野公园 Qingxi Country Park (QX)	远郊 Outer suburb	0.217	0.469	31	33	10
廊下郊野公园 Langxia Country Park (LX)	远郊 Outer suburb	0.313	0.463	25	39	10
海湾郊野公园 Bay Country Park (BF)	远郊 Outer suburb	0.262	0.519	3	11	10
南汇临港新城 Nanhui Lingang New City (LG)	远郊 Outer suburb	0.530	0.353	-	28	10
长兴岛潘石镇 Changxing Island Panshi Town (PS)	远郊 Outer suburb	0.085	0.280	14	30	10
崇明岛陈家镇 Chongming Island Chenjia Town (CJ)	远郊 Outer suburb	0.570	0.281	-	28	10
总计 Total				165	407	150

	CP	BG	GQ	CS	SN	PJ	XY	WG	JB	QX	LX	BF	LG	PS	CJ
CP	-	8.921	10.583	7.182	6.970	7.395	7.299	5.691	8.779	8.835	7.912	6.766	6.943	12.184	19.107
BG	13.092	-	13.819	7.759	7.633	8.225	8.681	7.829	9.858	9.460	8.627	8.260	8.816	14.709	21.486
GQ	11.502	21.893	-	11.321	11.353	12.329	12.160	10.787	11.826	13.005	12.284	11.578	11.779	14.775	21.914
CS	38.632	26.020	44.400	-	3.223	6.173	6.094	5.651	5.873	4.033	4.085	5.543	6.352	12.049	18.753
SN	38.143	25.329	47.017	14.861	-	5.695	5.540	5.228	6.495	4.721	3.481	4.975	5.877	12.014	18.738
PJ	20.314	13.272	31.584	30.861	23.018	-	5.935	5.435	8.586	7.787	6.666	5.698	6.356	12.952	19.726
XY	30.711	27.821	42.069	43.910	32.645	15.007	-	4.826	8.526	7.674	6.447	4.485	5.339	12.598	19.361
WG	18.445	22.859	28.488	46.662	39.897	16.884	16.375	-	7.768	7.261	6.154	4.269	4.300	11.210	18.016
JB	38.090	34.177	34.380	32.553	45.087	46.981	61.885	55.283	-	7.615	7.402	7.972	8.546	12.503	19.053
QX	55.905	43.777	60.139	18.119	29.195	48.796	61.102	64.778	38.533	-	5.428	7.115	7.946	13.715	20.421
LX	60.891	48.251	69.988	31.233	22.971	43.667	48.216	59.805	63.727	33.378	-	5.858	6.782	12.937	19.659
BF	41.736	40.070	52.729	55.036	42.461	27.280	12.290	24.799	74.170	71.550	54.098	-	4.068	11.904	18.654
LG	40.987	46.146	49.087	68.159	58.566	37.302	26.395	23.480	78.639	86.020	74.354	22.382	-	11.801	18.530
PS	24.212	36.120	14.477	58.697	61.387	44.372	52.475	36.883	43.953	73.881	84.346	61.639	52.830	-	13.680
CJ	39.235	51.594	30.122	74.281	76.911	58.910	65.210	48.951	56.961	89.118	99.844	72.958	60.178	15.649	-

	CP	BG	GQ	CS	SN	PJ	XY	WG	JB	QX	LX	BF	LG	PS	CJ
CP	-	8.921	10.583	7.182	6.970	7.395	7.299	5.691	8.779	8.835	7.912	6.766	6.943	12.184	19.107
BG	13.092	-	13.819	7.759	7.633	8.225	8.681	7.829	9.858	9.460	8.627	8.260	8.816	14.709	21.486
GQ	11.502	21.893	-	11.321	11.353	12.329	12.160	10.787	11.826	13.005	12.284	11.578	11.779	14.775	21.914
CS	38.632	26.020	44.400	-	3.223	6.173	6.094	5.651	5.873	4.033	4.085	5.543	6.352	12.049	18.753
SN	38.143	25.329	47.017	14.861	-	5.695	5.540	5.228	6.495	4.721	3.481	4.975	5.877	12.014	18.738
PJ	20.314	13.272	31.584	30.861	23.018	-	5.935	5.435	8.586	7.787	6.666	5.698	6.356	12.952	19.726
XY	30.711	27.821	42.069	43.910	32.645	15.007	-	4.826	8.526	7.674	6.447	4.485	5.339	12.598	19.361
WG	18.445	22.859	28.488	46.662	39.897	16.884	16.375	-	7.768	7.261	6.154	4.269	4.300	11.210	18.016
JB	38.090	34.177	34.380	32.553	45.087	46.981	61.885	55.283	-	7.615	7.402	7.972	8.546	12.503	19.053
QX	55.905	43.777	60.139	18.119	29.195	48.796	61.102	64.778	38.533	-	5.428	7.115	7.946	13.715	20.421
LX	60.891	48.251	69.988	31.233	22.971	43.667	48.216	59.805	63.727	33.378	-	5.858	6.782	12.937	19.659
BF	41.736	40.070	52.729	55.036	42.461	27.280	12.290	24.799	74.170	71.550	54.098	-	4.068	11.904	18.654
LG	40.987	46.146	49.087	68.159	58.566	37.302	26.395	23.480	78.639	86.020	74.354	22.382	-	11.801	18.530
PS	24.212	36.120	14.477	58.697	61.387	44.372	52.475	36.883	43.953	73.881	84.346	61.639	52.830	-	13.680
CJ	39.235	51.594	30.122	74.281	76.911	58.910	65.210	48.951	56.961	89.118	99.844	72.958	60.178	15.649	-

空间距离 Spatial distance	F_ST		F_ST/(1-F_ST)
空间距离 Spatial distance	SSR	SNP	SSR	SNP
欧氏距离 Euclidean distance	0.030	0.005	0.031	0.005
阻力距离 Resistance distance	0.593**	0.420*	0.598**	0.419*
