中国沿海洛氏角毛藻复合群的多样性组成及地理分布 |
陈作艺,许晓静,朱素英,翟梦怡,李扬 |
Species diversity and geographical distribution of the Chaetoceros lorenzianus complex along the coast of China |
Chen Zuoyi,Xu Xiaojing,Zhu Suying,Zhai Mengyi,Li Yang |
图6 稀树角毛藻的光学显微镜(LM) (A-B)、扫描电镜(SEM) (C-D, I-J)和透射电镜(TEM) (E-H)示意图。A: 链状群体; B: 休眠孢子位于母细胞链中; C: 链中壳面, 示重叠硅质翼(箭型)及壳套基部凹槽(箭头); D: 释放的成熟休眠孢子; E: 链端壳面, 示中央唇形突(箭头)和硅质肋纹(箭型); F: 壳套; G: 链中壳面, 示中央环纹(箭型); H: 环带; I-J: 角毛结构。标尺 = 20 μm (A), 10 μm (D), 4 μm (C, D, E), 2 μm (F), 1 μm (G, H, I, J)。 |
Fig. 6 Morphology of Chaetoceros pauciramosus under light microscopy (LM) (A-B), scanning electron microscopy (SEM) (C-D, I-J) and transmission electron microscopy (TEM) (E-H). A, Chain in broad girdle view; B, Resting spores within the mother cells of a chain; C, Sibling intercalary valves showing overlapping silica ear-like structures (arrows) and furrow above the basal ring of mantle (arrowhead); D, Released resting spore; E, Terminal valve with short external tubes of rimoportulae (arrowhead) and silica rib (arrows); F, Mantle; G, Intercalary valve, showing central annulus (arrow); H, Girdle bands; I and J, Seta structure. Scale bars, 20 μm (A), 10 μm (D), 4 μm (C, D, E), 2 μm (F), 1 μm (G, H, I, J). |
![]() |
